2600S-900-01 Rev. C / January 2008 Return to Section Topics 2-3
Series 2600 System SourceMeter
®
Instruments User’s Manual Section 2: Remote Operation
Step 3: Configure the interface
GPIB interface configuration
Set the primary address using the following procedure. The Series 2600 primary address must be
the same as that specified in your program, or the two devices will not be able to communicate.
1. Press MENU > GPIB and then press the ENTER.
2. Select ADDRESS and then press the ENTER.
The Address screen displays.
3. Turn the navigation wheel to the right or to the left to select the desired number.
4. Push in on the navigation wheel and then turn the navigation wheel to the left or to the
right to choose an address.
NOTE The address can range from 1-30.
5. Press the navigation wheel to set the address.
6. Press EXIT to until the Main Menu displays.
RS-232 interface configuration
Set RS-232 parameters as covered below. The Series 2600 RS-232 parameters must agree with
those of the computer serial port, or the two devices will not be able communicate.
1. Press MENU to view the main menu.
2. Choose RS-232, then press ENTER.
3. Choose the following options:
–Select BAUD and then choose the desired option.
– Choose BITS and then select the appropriate option.
–Select PARITY and then choose the desired.
– Choose FLOW-CTRL and then select the appropriate option.
6. Press EXIT until the Main Menu displays.
How do I use Test Script Builder?
Reference See Section 2 of the Series 2600 Reference Manual for complete details on using
the Test Script Builder.
Step 1: Run Test Script Builder
Run the Test Script Builder program in the Keithley Instruments folder in the usual manner. The
initial startup screen shown in
Figure 2-3 on page 2-5 will be displayed. The main sections of the
screen are briefly described below.
Main Bar
The menu contain following options:
File – Use this option to control projects and files.
Edit – Performs a number of editing functions on script files.
Navigate – Navigates through projects.
Project – Opens, closes, and builds projects.
To Next Page
