22 Quick Results Guide
NOTE Rel can also be used to establish a baseline reading. The baseline reading will be
subtracted from present and future readings. See “Relative” in Section 7 of the
Model 6430 SourceMeter Instruction Manual for details.
Remote command programming
The SCPI commands for speed, digits, filter, and rel are listed in Table 13. The commands for
ranging are listed in Tables 7 and 8.
Table 13
SCPI commands: speed, digits, filter, and rel
Command Description
Speed commands
1
:
[:SENSe]:CURRent:NPLCycles <n> Set measurement speed: <n> = 0.01 to 10.
[:SENSe]:VOLTage:NPLCycles <n> Set measurement speed: <n> = 0.01 to 10.
[:SENSe]:RESistance:NPLCycles <n> Set measurement speed: <n> = 0.01 to 10.
Digits command:
:DISPlay:DIGits <n> Set display resolution: <n> = 4, 5, 6, or 7.
Auto filter command:
[:SENSe]:AVERage:AUTO <b> Enable/disable auto filter: <b> = ON or OFF.
Repeat filter commands:
[:SENSe]:AVERage:REPeat:COUNt <n> Set repeat filter count: <n> = 1 to 100.
[:SENSe]:AVERage:REPeat[:STATe] <b> Enable/disable repeat filter: <b> = ON or OFF.
Median filter commands:
[:SENSe]:MEDian:RANK <NRf> Set median filter rank: <NRf> = 0 to 5.
[:SENSe]:MEDian[:STATe] <b> Enable/disable median filter: <b> = ON or OFF.
Moving filter commands:
[:SENSe]:AVERage:COUNt <n> Set average filter count: <n> = 1 to 100.
[:SENSe]:AVERage[:STATe] <b> Enable/disable filter: <b> = ON or OFF.
[:SENSe]:AVERage:ADVanced:NTOLerance <NRf> Set advanced filter noise window: <NRf> = 0 to 105.
[:SENSe]:AVERage:ADVanced[:STATe] <b> Enable/disable advance filter: <b> = ON or OFF.
Rel command
2
:
:CALCulate2:NULL:STATe <b> Enable/disable rel: <b> = ON or OFF.
1. The speed setting is global for all functions. Therefore, you can use any of the three commands to set speed.
2. The commands to acquire a rel value are not listed in this table (see Section 7 Relative in the Model 6430 SourceMeter Instruction
Manual).
