Introduction .............................................................................. 4-1

Equipment required for this example ........................................ 4-1

Device connections .................................................................. 4-2

Basic front-panel measurements .............................................. 4-3

Introduction

This example application makes a 2-wire resistance measurement using the front panel of the

instrument.

Set the function before making other instrument settings. Many of the settings are related to a

specific measure function. The applications in this manual use the order of operations to produce the

best results.

Equipment required for this example

Equipment required to perform this test:

• One DMM6500

• Two insulated banana cables.

• One resistor to test, the example uses a resistor with a 9.75 kΩ rating

Section 4

Making basic front-panel measurements

Keithley DMM6500 User Manual
