3: Using a remote interface Model 2460 Interactive SourceMeter® Instrument
3-14 2460-900-01 Rev. A / September 2014
Web interface Home page
Figure 16: Model 2460 web page
The Home page of the instrument provides information about the instrument. It includes:
• The instrument model number, manufacturer, serial number, and firmware revision number.
• The TCP Raw Socket number and Telnet Port number.
• The last LXI message. The history link opens the LXI Home page.
• The ID button, which allows you to identify the instrument. Refer to Identify the instrument (on
page 3-15).
You can also control some instrument functions from the web interface:
• The Virtual Front Panel page allows you to control the instrument as if you were using the front
panel. For details, see "Using the Model 2460 virtual front panel" in the Model 2460 Reference
Manual.
• You can send single-line commands from the Send Commands page of the web interface.
