Before Use
Sound Effects Menu
Tone curve setup
You can set a Tone curve.
1 Display the Tone setup screen
Tone
(Page 80 7)
Tone setup screen
1
2
3
5
4
6
1
1
1
7
1 Adjusts the volume.
2 Bass adjustment items are displayed.
3 Middle adjustment items are displayed.
4 Treble adjustment items are displayed.
5 Bass DC Extend settings
If turned "On", it extends the bass center
frequency to the low register by approximately
20%.
6 Tone curve becomes flat.
7 Returns to the Equalizer screen.
• Tone curve can be set for each source.
2 Select a frequency band you wish to adjust
You can adjust the following frequency bands.
Bass: 40, 50, 60, 70, 80, 100, 120, 150 Hz
Middle: 500, 1k, 1.5k, 2k Hz
Treble: 10k, 12.5k, 15k, 17.5k Hz
3 Set a center frequency
FREQ
4 Set a level
Level
5 Set a Q factor
Q Factor
You can set it up only when Bass or Middle is
adjusted.
6 Close the Tone setup screen
