PARTS LIST
40
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L : Scandinavia K: USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Europe
Y : AAFES (Europe) X: Australia M: Other Areas
TK-890
TK-890(B)
New Desti-
parts nation
Ref. No. Address Parts No. Description
New Desti-
parts nation
Ref. No.
Address Parts No. Description
1 3A A01-2161-02 CABINET (UPPER)
2 1A A01-2162-02 CABINET (LOWER)
32B✽ A10-1388-11 CHASSIS
42A✽ A62-0606-13 PANEL ASSY (KCH-10)
6 3A,3B B42-2455-04 STICKER (M4X8 MAX)
7 1J B46-0470-00 WARRANTY CARD ACSY
81J✽ B62-0970-10 INSTRUCTION MANUAL
- ✽ B72-1454-24 MODEL NAME PLATE
11 2B E04-0167-05 RF COAXIAL PECEPTACLE (M)
12 1I ✽ E30-3318-15 DC CORD ASSY ACSY
13 2A E31-3269-05
LEAD WIRE WITH MINIPIN PLUG (RA/DO)
14 2B E37-0708-05 LEAD WIRE WITH CONNECTOR (ACC:9P)
15 1B E37-0728-05 LEAD WIRE WITH CONNECTOR (DC:2P)
16 1B,2I E37-0733-05 SHORT PLUG (SP) ACSY
17 2B ✽ E37-0772-15
LEAD WIRE WITH CONNECTOR (D-SUB:25P)
18 3A E37-0776-05 FLAT CABLE (CONT-TX:18P)
- E37-0787-05
LEAD WIRE WITH CONNECTOR (KCH-10)
21 2I F05-1537-05 FUSE (BLADE) (15A/32V) ACSY
23 2B F09-0445-05 CAP (D-SUB)
24 1B F10-1479-03 SHIELDING PLATE (FINAL)
22 2I F29-0472-04 INSULATING COVER ACSY
26 2A G02-0599-04 FLAT SPRING (APC)
27 3A G02-0709-04 FLAT SPRING (AUDIO AMP)
28 3A G02-0715-04 FLAT SPRING (AVR)
29 2B G53-0712-03 PACKING (DC,ACC)
- G53-0838-03 PACKING (KCH-10:PANEL ASSY)
- G53-0839-14 PACKING (KCH-10:SP)
32 3B G53-0869-03 PACKING (CABINET UPPER)
33 1A ✽ G53-0900-03 PACKING (CABINET LOWER)
- ✽ G53-1523-04 PACKING (KCH-10:VOL)
36 2J H10-6621-02 POLYSTYRENE FOAMED FIXTURE
35 1J H11-0896-04 POLYSTYRENE FOAMED BOARD
38 1I H12-1403-04 PACKING FIXTURE
39 2J H13-1066-04 CARTON BOARD
40 2I H25-0029-04 PROTECTION BAG (60/110/0.07)
42 2I H25-0103-04 PROTECTION BAG (125/250/0.07)
43 2I H25-0117-04 PROTECTION BAG (80/250/0.07)
44 1J H25-0194-04 PROTECTION BAG (280/400/0.07)
41 2I ✽ H25-2063-04 PROTECTION BAG (80/120/0.03)
45 3J H52-1230-02 ITEM CARTON CASE
46 2I J19-1584-05 HOLDER (MIC) ACSY
47 1B J21-8346-04 HARDWARE FIXTURE (DC,ACC)
- ✽ J21-8417-04
HARDWARE FIXTURE (KCH-10:MIC CONNECTOR)
48 2I J29-0422-13 BRACKET ACSY
- J39-0625-04 SPACER (KCH-10:TX-BUSY)
50 2I J61-0307-05 BAND ACSY
- K29-4664-04 KNOB (KCH-10:VOL,UP/DOWN)
53 2I K29-4704-04 KNOB ACSY
- K29-5251-12 KEY TOP (KCH-10)
55 2I K29-5276-03 KNOB ACSY
56 2I K29-5277-03 KNOB ACSY
57 2I K29-5305-03 KNOB ACSY
TK-890
A 2B N09-2292-05 HEXAGON HEAD SCREW
B 2A,2B N32-3006-46 FLAT HEAD MACHINE SCREW
C 1A,3B N33-3006-45 OVAL HEAD MACHINE SCREW
D 1A,2A N35-3006-46 BINDING HEAD MACHINE SCREW
E 2B N67-3008-46 PAN HEAD SEMS SCREW W
- N87-2605-46
BRAZIER HEAD TAPTITE SCREW (KCH-10)
G 2A,3B N87-2606-46 BRAZIER HEAD TAPTITE SCREW
- N87-2608-46
BRAZIER HEAD TAPTITE SCREW (KCH-10)
J 1A N87-2612-46 BRAZIER HEAD TAPTITE SCREW
- N87-3006-46
BRAZIER HEAD TAPTITE SCREW (KCH-10)
L 1B,2B N87-3008-46 BRAZIER HEAD TAPTITE SCREW
59 2I N99-0321-05 SCREW SET ACSY
- T07-0265-05 SPEAKER (KCH-10)
62 1I ✽ T91-0587-25 MICROPHONE (KMC-27) ACSY
1 3A A01-2161-02 CABINET (UPPER)
2 1A A01-2162-02 CABINET (LOWER)
32B✽ A10-1388-11 CHASSIS
6 3A,3B B42-2455-04 STICKER (M4X8 MAX)
7 1J B46-0470-00 WARRANTY CARD ACSY
81J✽ B62-0970-10 INSTRUCTION MANUAL
- ✽ B72-1454-24 MODEL NAME PLATE K
- ✽ B72-1456-14 MODEL NAME PLATE K2
- ✽ B72-1457-24 MODEL NAME PLATE K3
11 2B E04-0167-05 RF COAXIAL PECEPTACLE (M)
13 2A E31-3269-05
LEAD WIRE WITH MINIPIN PLUG (RA/DO)
14 2B E37-0708-05 LEAD WIRE WITH CONNECTOR (ACC:9P)
15 1B E37-0728-05 LEAD WIRE WITH CONNECTOR (DC:2P)
16 1B,2I E37-0733-05 SHORT PLUG (SP) ACSY
17 2B ✽ E37-0772-15
LEAD WIRE WITH CONNECTOR (D-SUB:25P)
18 3A E37-0776-05 FLAT CABLE (CONT-TX:18P)
23 2B F09-0445-05 CAP (D-SUB)
24 1B F10-1479-03 SHIELDING PLATE (FINAL)
22 2I F29-0472-04 INSULATING COVER ACSY
26 2A G02-0599-04 FLAT SPRING (APC)
27 3A G02-0709-04 FLAT SPRING (AUDIO AMP)
28 3A G02-0715-04 FLAT SPRING (AVR)
29 2B G53-0712-03 PACKING (DC,ACC)
32 3B G53-0869-03 PACKING (CABINET UPPER)
33 1A ✽ G53-0900-03 PACKING (CABINET LOWER)
36 2J H10-6621-02 POLYSTYRENE FOAMED FIXTURE
37 2J H11-0892-04 POLYSTYRENE FOAMED BOARD
35 1J H11-0896-04 POLYSTYRENE FOAMED BOARD
38 1I H12-1403-04 PACKING FIXTURE
39 2J H13-1066-04 CARTON BOARD
42 2I H25-0103-04 PROTECTION BAG (125/250/0.07)
44 1J H25-0194-04 PROTECTION BAG (280/400/0.07)
41 2I ✽ H25-2063-04 PROTECTION BAG (80/120/0.03)
45 3J H52-1231-12 ITEM CARTON CASE
TK-890(B)
