TS-480HX/480SAT
140
ACCESSORIES
PG-20 (DC Cable : 7m)
PG-4Z (Extension Cable Kit)
VGS-1 (Voice Guide & Storage Unit)
SO-3 (TCXO Unit)
YF-107C (500Hz CW Filter)
YF-107CN (270Hz CW Narrow Filter)
YF-107SN (1.8kHz SSB Narrow Filter)
ARCP-480 (Radio Control Program)
ARHP-10 (Radio Host Program)
Available free for downloading from the KENWOOD website:
http:www.kenwood.com/i/products/info/amateur.html

Table of Contents

Other manuals for Kenwood TS-480SAT

Preview: Instruction Manual
Instruction Manual106 pages
Preview: Setting Manual
Setting Manual26 pages
Preview: Reference Guide
Reference Guide26 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kenwood TS-480SAT and is the answer not in the manual?

Kenwood TS-480SAT Specifications

General IconGeneral
Antenna Impedance50 ohms
Supply Voltage13.8 V DC ±15%
Current Drain (Receive)1.5 A
Antenna ConnectorSO-239
Operating Temperature-10°C to +50°C
ModesSSB, CW, AM, FM, FSK
Antenna TunerBuilt-in
Current Drain (Transmit)20.5 A
Power Output100 watts
RF Output Power100 watts
