Kenwood TS-480SAT Service Manual

TS-480HX/480SAT
50
EXPLODED VIEW (MAIN BODY UPPER SIDE)
3
2
1
BA
8
15
63
70
70
62
63
1
55
41
77x2
54
59
43
40
39
39
27
27
3
65
66
67
5
50
D
D
D
D
D
Dx2
D
Lx12
L
L
L
L
L
L
L
Lx2
Lx2
Lx11
Final unit
(B/3)
TX-RX unit
(A/2)
TX-RX unit
(B/2)
Final unit
(C/3)
D M2.6 x 6 (OC) BLK : N33-2606-45
L M2.6 x 8 (Br-Tap) : N87-2608-46
Parts with the exploded numbers larger than 700 are not supplied.

Kenwood TS-480SAT Specifications

General

Antenna Impedance	50 ohms
Supply Voltage	13.8 V DC ±15%
Current Drain (Receive)	1.5 A
Antenna Connector	SO-239
Operating Temperature	-10°C to +50°C
Modes	SSB, CW, AM, FM, FSK
Antenna Tuner	Built-in
Current Drain (Transmit)	20.5 A
Power Output	100 watts
RF Output Power	100 watts
