Kenwood TS-480SAT Service Manual

TS-480HX/480SAT
27
KH : TS-480HX (K) KS : TS-480SAT (K)
EH : TS-480HX (E) ES : TS-480SAT (E)
PARTS LIST
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Europe
Y : AAFES (Europe) X : Australia M :Other Areas
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
11B✽ A01-2189-02 CABINET (UPPER)
2 1D,1F ✽ A01-2190-02 CABINET (LOWER)
3 3A,3F ✽ A10-4061-01 CHASSIS KH,EH
3 3A,3D ✽ A10-4062-01 CHASSIS KS,ES
43G✽ A62-1076-03 PANEL ASSY
53A✽ A62-1079-01 PANEL
61H✽ A82-0052-11 REAR PANEL
81B✽ B03-3610-03 DRESSING PLATE
9 1D,1F B42-2455-04 STICKER
10 1C,1E B42-5650-04 S/NO. LABEL
11 1J B42-7003-04 RATING LABEL (DC CORD) EH,ES
12 1D,1F B42-7019-04 STANDARD LABEL (FCC) KH,KS
14 1C,1E B42-7070-04 STANDARD LABEL (FCC) KH,KS
15 1B B42-7116-04 STICKER (ANT)
14 1C,1E B42-7126-04 STANDARD LABEL (E-MARK) EH,ES
17 1K ✽ B52-0619-00 SCHEMATIC DIAGRAM KH,KS
18 1K ✽ B52-0620-10 SCHEMATIC DIAGRAM KH,KS
19 1K ✽ B62-1735-10 INSTRUCTION MANUAL (ENGLISH)
20 1K ✽ B62-1736-10 INSTRUCTION MANUAL (GERMANY) EH,ES
21 1K ✽ B62-1750-10 INSTRUCTION MANUAL (FRENCH) EH,ES
22 1K ✽ B62-1751-10 INSTRUCTION MANUAL (ITALIAN) EH,ES
23 1K ✽ B62-1752-10 INSTRUCTION MANUAL (SPANISH) EH,ES
24 1K ✽ B62-1753-10 INSTRUCTION MANUAL (DOUCHE) EH,ES
25 1E ✽ B72-2166-04 MODEL NAME PLATE KH
25 1C ✽ B72-2167-04 MODEL NAME PLATE KS
25 1E ✽ B72-2168-04 MODEL NAME PLATE EH
25 1C ✽ B72-2169-04 MODEL NAME PLATE ES
27 3B E30-3009-15 ANTENNA CABLE (ANT)
28 1J ✽ E30-3488-05 MODULAR CABLE (PANEL, 4M)
29 1J,2J ✽ E30-3489-05 DC CORD
30 1J ✽ E30-3500-05 MODULAR CABLE (PANEL, 20CM) EH,ES
- ✽ E37-1059-05
LEAD WIRE WITH CONNECTOR (X57 CN369)
- ✽ E37-1060-05 LEAD WIRE WITH MINIPIN PLUG (X57 CN501)
- ✽ E37-1061-05 LEAD WIRE WITH MINIPIN PLUG (X57 CN3)
- ✽ E37-1062-05 LEAD WIRE WITH MINIPIN PLUG (X57 CN1)
- ✽ E37-1063-05 LEAD WIRE WITH MINIPIN PLUG (X44 CN2)
- ✽ E37-1064-05 LEAD WIRE WITH MINIPIN PLUG (X44 CN1)
- ✽ E37-1067-05 LEAD WIRE WITH MINIPIN PLUG (X45 CN504) KS,ES
- ✽ E37-1068-05
LEAD WIRE WITH MINIPIN PLUG (X45 CN505) KS,ES
39
2A,2D,2F ✽ E37-1069-05 FLAT CABLE (X57 CN395,403)
40 2A ✽ E37-1070-05 FLAT CABLE (X57 CN375)
41 2B ✽ E37-1071-05 FLAT CABLE (X45 CN501)
42 1G ✽ E37-1072-05 LEAD WIRE WITH CONNECTOR (SP)
43 2A ✽ E37-1073-05
LEAD WIRE WITH CONNECTOR (EXT. AT)
44 1K ✽ E57-0404-05 DIN PLUG (6P ACC)
45 1K ✽ E57-0405-05 DIN PLUG (8P ACC)
47 1J,1K F05-2531-05 FUSE (BLADE) (25A/32V)
48
2D,2F,1K F06-4027-05 FUSE (BLADE) (4A/32V)
49 3C,3E ✽ F07-1874-05 COVER (FAN)
50 3A ✽ F07-1875-13 COVER (DIN, SP, KEY)
51 3C ✽ F07-1878-04 COVER (FAN) KS,ES
52 3C,3E ✽ F09-0478-05 FAN MOTOR
53 2D,2F ✽ F10-2450-02 SHIELDING COVER (X45 A/3)
54 2A ✽ F10-2456-03 SHIELDING COVER (X57 A/2)
55 2B ✽ F10-2470-02 SHIELDING COVER (X45 B/3)
56 3C ✽ F15-1007-04 SHIELDING PLATE (DC2) KS,ES
58 3G G02-0505-05 KNOB SPRING
59 2A G02-0570-04 FLAT SPRING (X57 IC734)
60 3G ✽ G02-0898-04 FLAT SPRING (TORQUE LEVER)
61 3G G09-0405-05 KNOB SPRING
62 1B ✽ G10-1305-04 FIBROUS SHEET
63 1B ✽ G10-1306-04 FIBROUS SHEET
64 1D,1F ✽ G10-1307-04 FIBROUS SHEET
65 3A ✽ G10-1308-04 FIBROUS SHEET
66 3A ✽ G10-1309-04 FIBROUS SHEET
67 3A ✽ G10-1310-04 FIBROUS SHEET
68 1H ✽ G10-1311-04 FIBROUS SHEET
69 3G ✽ G10-1313-14 FIBROUS SHEET
- G10-1326-04 FIBROUS SHEET
70 1B G10-1328-04 FIBROUS SHEET
71 1K ✽ G11-4228-04 SHEET
72 1H ✽ G11-4245-04 SHEET
73 1K ✽ G11-4269-04 SHEET
74 3H ✽ G11-4270-04 SHEET
75 2H,3H ✽ G11-4278-04 SHEET
76 2H,3H G11-4287-04 SHEET
77 2A G13-1871-05 CONDUCTIVE CUSHION
78 2F G13-1872-05 CONDUCTIVE CUSHION KH,EH
79 2H G13-1888-04 CUSHION
80 1J ✽ G13-2022-14 CUSHION
81 1H ✽ G13-2024-04 CUSHION
82 1H ✽ G53-1559-02 PACKING
83 2J ✽ H12-3142-02 PACKING FIXTURE
84 2K ✽ H12-3153-02 PACKING FIXTURE
85 2K ✽ H12-3154-02 PACKING FIXTURE
86 1K H25-0029-04 PROTECTION BAG (60/110/0.07)
87 1J,2J H25-0796-04 PROTECTION BAG
88 1K H25-2013-04 PROTECTION BAG (80✽180 T=0.08) EH,ES
89 1K H25-2320-04 PROTECTION BAG
90 1J,1K ✽ H25-2327-04 PROTECTION BAG (100/250/0.07)
91 1J,1K ✽ H25-2343-04 PROTECTION BAG
92 1K,2K ✽ H25-2352-04 PROTECTION BAG (250/350/0.07)
93 3K ✽ H52-1944-02 ITEM CARTON CASE KH
93 3K ✽ H52-1945-02 ITEM CARTON CASE KS
93 3K ✽ H52-1946-02 ITEM CARTON CASE EH
93 3K ✽ H52-1947-02 ITEM CARTON CASE ES
95 1D,1F J02-0441-05 FOOT
96 1K ✽ J09-0409-03 STAND
97 1G ✽ J21-8449-04 HARDWARE FIXTURE
98 1J ✽ J29-0663-13 BRACKET
99 1K ✽ J29-0705-01 BRACKET EH,ES
100 1K ✽ J29-0706-04 BRACKET
101 1K ✽ J29-0707-03 BRACKET
- J61-0307-05 BAND
104 1J K01-0420-05 HANDLE EH,ES
105 3G ✽ K21-1105-03 KNOB (MAIN DIAL)
106 3H ✽ K29-9263-02 KEY TOP
TS-480HX/480SAT
TS-480HX/480SAT (Y52-328X-XX)

Kenwood TS-480SAT Specifications

General

Antenna Impedance	50 ohms
Supply Voltage	13.8 V DC ±15%
Current Drain (Receive)	1.5 A
Antenna Connector	SO-239
Operating Temperature	-10°C to +50°C
Modes	SSB, CW, AM, FM, FSK
Antenna Tuner	Built-in
Current Drain (Transmit)	20.5 A
Power Output	100 watts
RF Output Power	100 watts
