Keysight N4693D User Manual

Electronic Calibration Modules Reference Guide 5-13
Specifications and Characteristics
Characteristic Performance
N4432D (Type-N 50 Ω – Microwave)
The characteristic performance in the following table applies to N4432D
Option 020 (Type-N female connectors on all ports). The data describes
performance when measuring “thru path” A-B, C-D, A–D, A-D, B–C, and B-D.
N4433D (3.5 mm – Microwave)
The characteristic performance in the following table applies to N4433D
Option 010 (3.5 mm female connectors on all ports). The data describes
performance when measuring “thru path” A-B, C-D, A–D, A-D, B–C, and B-D.
Table 5-23 Characteristic Performance for N4432D Option 020
a
Parameter Frequency Range
DC to 10 MHz
b
300 kHz to 10
MHz
c
10 MHz to
5 GHz
5 GHz to
9 GHz
9 GHz to 13.5
GHz
13.5 GHz to
18 GHz
Transmission
Tracking (±dB)
d
0.17 0.18 0.05 0.09 0.13 0.19
Load Match (dB)
d
37 35 42 39 35 33
a. When applied power exceeds –7 dBm, calibration results will be degraded from the performance indicated in this table.
b. For Option 0DC.
c. For option 003.
d. Values based on using the network analyzer N5232B 400.
Table 5-24 Characteristic Performance for N4433D Option 010
a
Parameter Frequency Range
DC to
10 MHz
b
300 kHz
to 10
MHz
c
10 MHz
to 5 GHz
5 GHz to
9 GHz
9 GHz to
13.5 GHz
13.5 to
20 GHz
20 GHz to
26.5 GHz
Transmission Tracking
(±dB)
d
0.08 0.12 0.08 0.11 0.12 0.22 0.38
Load Match (dB)
d
39 33 39 36 34 28 23
a. When applied power exceeds –7 dBm, calibration results will be degraded from the performance indicated in this table.
b. For Option 0DC.
c. For option 003.
d. Values based on using the network analyzer N5222B 405.
