5-14 Electronic Calibration Modules Reference Guide
Specifications and Characteristics
Characteristic Performance
5-
N469xD Series
Table 5-25 Characteristic Performance for N4690D (Type-N 50Ω)
Parameter Frequency Range
DC to
2 MHz
a
a. For option 0DC.
2 MHz to
10 MHz
a
300 kHz
to 2 MHz
b
b. For option 003.
2 MHz
to 10 MHz
b
10 MHz to
500 MHz
500 MHz
to 2 GHz
2 GHz
to 10 GHz
10 GHz
to 18 GHz
Transmission
Tracking (±dB)
0.17
c
c. Values based on using the network analyzer N5231B Option 200.
0.06
c
0.37
c
0.08
c
0.10
d
d. Values based on using the network analyzer N5222B Option 200.
0.04
d
0.05
d
0.09
d
Load Match (dB)
36
c
41
c
26
c
37
c
33
d
42
d
39
d
34
d
Table 5-26 Characteristic Performance for N4691D (3.5 mm)
Parameter Frequency Range
DC to
2 MHz
a
a. For Option 0DC.
2 MHz to
10 MHz
c
300 kHz
to
2 MHz
b
b. For Option 003.
2 MHz
to 10 MHz
b
10 MHz
to
500 MHz
500 MHz
to 2 GHz
2 GHz
to 10 GHz
10 GHz
to
20 GHz
20 GHz
to 26.5 GHz
Transmission
Tracking (±dB)
0.21
c
c. Values based on using the network analyzer N5231B Option 200.
0.06
c
0.37
c
0.08
c
0.09
d
d. Values based on using the network analyzer N5222B Option 200.
0.03
d
0.04
d
0.07
d
0.09
d
Load Match (dB)
34
c
41
c
27
c
37
c
34
d
46
d
43
d
40
d
38
d
