Keysight N4693D User Manual

5-6 Electronic Calibration Modules Reference Guide
Specifications and Characteristics
Electrical Specifications
5-
N4432D (Type-N 50 Ω)
The electrical performance in the following table applies to N4432D Option
020 (Type-N 50 Ω female connectors on all ports).
N4433D (3.5 mm)
The electrical performance in the following table applies to N4433D Option
010 (3.5 mm female connectors on all ports).
Table 5-9 Electrical Performance for N4432D Option 020
a
Parameter Frequency Range
DC to
10 MHz
b
300 kHz to
10 MHz
c
10 MHz to
5 GHz
5 GHz to
9 GHz
9 GHz to
13.5 GHz
13.5 GHz to
18 GHz
Directivity (dB) 50 45 50 47 41 40
Source Match (dB) 41 35 41 37 34 34
Reflection Tracking (±dB) 0.06 0.10 0.06 0.10 0.15 0.14
a. When applied power exceeds –7 dBm, calibration results will be degraded from the performance indicated in this table.
b. For Option 0DC.
c. For option 003.
Table 5-10 Electrical Performance for N4433D Option 010
a
Parameter Frequency Range
DC to
10 MHz
b
300 kHz to
10 MHz
c
10 MHz
to 5 GHz
5 GHz to
9 GHz
9 GHz to
13.5 GHz
13.5 to
20 GHz
20 GHz to
26.5 GHz
Directivity (dB) 50 45 50 47 45 40 36
Source Match (dB) 42 36 42 39 37 31 26
Reflection Tracking (±dB) 0.06 0.10 0.06 0.09 0.10 0.18 0.31
a. When applied power exceeds –7 dBm, calibration results will be degraded from the performance indicated in this table.
b. For Option 0DC.
c. For option 003.
