Be extra careful not to let any
part of your body under the
tractor or an implement when
lowering an implement.
WARNING
tb3O436A
HYDRAULIC SYSTEM
POSITION CONTROL LEVER
(1) Position Control Lever
(2) Lower Link
(A) Lowering (B) Lifting
The position control lever is to oper-
ate the hydraulic lift arm to lift and
lower a 3-point hitch implement.
To lower an implement, move the
lever forward. To raise an implement,
move the lever backward.
The position control lever is automat-
ically returned to its neutral position
when the lift arm reaches its upper
limit position.
When lifting and lowering the
lift arm, make sure to place
the position control lever to
the neutral position in order to
stop the lift arm at the desired
position.
IMPORTANT
Make sure that there is no one
around before lowering an imple-
ment.
WARNING
To Next Page
