40
kobalttools.com
ADJUSTMENTS
WARNING
Before performing any adjustment, make sure tool is unplugged from power supply and switch is in
o position. Failure to do so could result in serious personal injury.
The table saw has been adjusted at the factory for making very accurate cuts. However, some
components might have been jarred out of alignment during shipping. Also, over a period of time,
readjustment will probably become necessary due to wear.
Carefully check alignment with a framing square before beginning adjustments to conrm whether
they are necessary. Use test cuts after completing adjustments to avoid damaging workpiece.
To place riving knife in lowered position
(for non-through cuts):
Note: Remove throat plate (Y).
1. Raise the blade (W) by turning the height adjusting
wheel (P) clockwise.
2. Lift lever up and toward rear of saw. Push in on the nut
to release the riving knife for adjustment. Reinstall throat
plate.
