46
kobalttools.com
ADJUSTING BEVEL INDICATOR
• Adjust bevel indicator if it is not at zero when the blade is perpendicular to the table.
1. With blade perpendicular to table, loosen screw.
2. Set indicator to 0° on bevel scale.
3. Retighten screw.
CHECKING ALIGNMENT OF RIP FENCE TO
MITER SLOT
1. Turn power o.
2. Unplug saw.
3. Raise locking levers to permit rip fence (T) to be
moved.
4. Move fence so until it aligns with miter slot.
5. Lower locking levers.
6. Make two or three test cuts on scrap wood. If cuts are
not true, repeat process.
ADJUSTMENTS
ACCESSORY STORAGE
• Accessories can be stored in positions shown below.
