Section 5 Wiring Diagrams
5.1 Specification N umbers
At the time of print, this manual applied to the model
numbers and specification (spec) numbers in
Figure 5-1. On occasion the manufacturer may provide
this manual with units that are not listed below, such as
when similar new specs are created prior to the updated
reprint or in other cases when the manual is a suitable
substitute for a manual under development.
Model No. Spec. No.
8.5RES GM29253-GA1
12RES GM29253-GA2
Figure 5-1 Generator Set S pecification Numbers
5.2 Controller Wiring Diagram
Reference
Figure 5-2 lists the wiring diagram numbers and
locations.
Wiring Diagram Description
Drawing
Number
Page
Schematic Diagram
Sheet 1
Sheet 2
ADV-6835A
ADV-6835B
22
23
Point-to-Point Wiring Diagram GM29358 24
Figure 5-2 Controller Wiring Diagrams

Kohler 12RES Specifications

General

Voltage	120/240 V
Frequency	60 Hz
Power Output	12, 000 watts
Phase	Single
Starting System	Automatic
Transfer Switch	Optional
