TP-5393 9/93 Specifications 1-1
Section 1. Specifications
Introduction
Your vehicle is equipped with a dependable Kohler
alternating-current generator set. Service
requirements of the generator set are minimal but it is
important that the required services be performed at
theprescribedintervals.Pleasetakeafewmomentsto
read through this manual then carefully follow all
service recommendations to keep your set in top
conditions. In the space provided,record the MODEL,
SPECIFICATION, SERIAL and ENGINE SPEC.
numbers as found on the nameplate attached to the
controller of the generator (see “Section 8. Service
Ordering Instructions”). This information will enable
your Kohler generator service dealer/distributor to
supply the correct part or data for your particular
version. Keep this manual in your vehicle for future
reference.
Specifications
General Specifications
4CKM/CKMR (60Hz) 5CKM/CKMR (60Hz)
Dimensions—L x W x H—in. (mm) 24.83 x 18.46 x 13.98
(631 x 469 x 355)
24.83 x 18.46 x 13.98
(631 x 469 x 355)
Weight—lbs. (kg) 258 (117) 268 (121.5)
Air Requirements:
Combustion—cfm 20 20
Cooling—cfm 340 340
Free Air Opening 85 sq. in. (548 sq. cm) 85 sq. in. (548 sq. cm)
4CFKM/CFKMR (50Hz)
Dimensions—L x W x H—in. (mm) 24.83 x 18.46 x 13.98 (631 x 469 x 355)
Weight—lbs. (kg) 258 (117)
Air Requirements:
Combustion—cfm 20
Cooling—cfm 340
Free Air Opening 85 sq. in. (548 sq. cm)
