TP-5393 9/93 Installation 6-1
Section 6. Installation
Introduction
Use this section as a guide when installing a generator
set in the recreational vehicle, then refer to the
Operation section for specific service instructions.
When installing an RV/Mobile generator set, the
installation must comply with the Kohler detailed
installationinstructions.Specificinstallationinstructions
for RV generator sets begin on page 6-5. Mobile
installation instructions begin on page 6-9. Any
additional requirements can also be found in the
following two sources: (1) ANSI A 119.2/NFPA 501 C
and(2)article551of ANSI/NFPA 70, NationalElectrical
Code. Generator set installation must also comply with
state and local requirements.
NOTE
This generator set does not comply with United
States Coast Guard (U.S.C.G.) requirements and
must not be used for marine applications. Use only
generator sets specified for marine use in marine
installations. U.S.C.G. Regulation33CFR183 requires
ageneratorset tobe“ignitionprotected”whenusedina
gasoline-fueled environment.
General Information
ThissectioncoverstheRVandMobileKohlergenerator
set installation. To determine which model is involved,
check the model number found on the nameplate
attached to the controller of the generator being
installed. Follow all instructions to insure proper
installation.
Features
All models feature Kohler designed and built 4-cycle
air-cooled gasoline engines, rotating field Alternating
Current generators, and Relay Controllers. Each
generator is directly connected to the Kohler engine for
permanent alignment. Permanent magnet type starting
motors are used to crank the engine during start-up.
EachControllerincludesaSTART-STOPswitch fortest
operating the set at the controller. The controller also
has a keyed connector for connecting a wiring harness
to a remote start-stop switch (usually located on the
dashboardofthevehicle). AllKohlerRV/Mobilesetsare
mountedonasteeldrippan-typemountingtrayforquick
installationtotheframeofthevehicle. Addoilasneeded
to the crankcase to bringthe level up to the max. mark.
Following are some general specifications.
Specifications
Weight (approx.) 5 kW 268 lbs. (121.5 kg)
Weight (approx.) 4 kW 258 lbs. (117.0 kg)
Air Requirements—Total Combustion 20 CFM—Cooling 340 CFM
Fuel Inlet Connection Size—Gasoline 5/16 in. I.D. (7.9 mm)
Fuel Type or LP Gas Liquid Withdrawal Unleaded Regular Gasoline, LP Gas Vapor,
Battery Voltage 12
Battery Recommendation (min.) 290 CCA, 90 Amp hr.
Battery Ground Negative
