Diagram of electric starting wiring system with ywheel
alternator (g. 47).
1.Battery - 2.Regulator - 3.Alternator - 4.Starter motor - 5.Pressure
gauge - 6.Oil pressure warning light - 7.Starter key - 8.Battery char-
ging light.
ELECTRICAL EQUIPMENT
Diagram of electric starting wiring system with external
alternator (g. 48).
1.Battery - 2.Regulator - 3.Alternator - 4.Starter motor - 5.Pressure
gauge - 6.Oil pressure warning light - 7.Starter key - 8.Battery char-
ging light.
