0,25 ÷ 0,35 mm
0,9 ÷ 1,1 1,8
In order to carry out this operation correctly, make the
check with the cylinder pressed well down on its crankcase
(g. 72).
The clearance is adjusted by means of shims inserted between the
lower face of the cylinder and crankcase (g. 73).
Shim dimensions: 0.1 to 0.2 mm
Cylinder height adjustement
Between the top face of the cylinder and the piston at top dead cen-
ter, there must be a clearance of:
Checking valve head face depth
When replacing valves check that the clearance from the top of the
head to the face (g. 74) is of:
For different values see on pages 18-19.
Checking injector protrusion
Before mounting the heads on the cylinders, insert injectors in their
housings and after having secured them temporarily, check protusion
of nozzles from head surface (g. 75).
Protusion S should be:
Fitting mm Max. wear mm
ENGINE ASSEMBLY
2,25 ÷ 2,75 mm
