Kohler XT-6 User Manual

6
Specications
KohlerEngines.com 14 690 01 Rev. G
TORQUE SPECIFICATIONS
3,5
XT-6, XTR-6
XT6.5, XT650,
XT6.75, XT675
XT-7, XTR-7,
XT775, XT8
Connecting Rod
Cap Fastener (torque in increments) 12.5 N·m (110 in. lb.)
Crankcase
Oil Drain Plug
7
13.6 N·m (120 in. lb.)
Oil Pan Screw 11.0 N·m (98 in. lb.) 14.7 N·m (130 in. lb.)
Cylinder Head
Fastener (torque in 2 increments) rst to 14 N·m (123 in. lb.)
nally to 27.8 N·m (246 in. lb.)
Flywheel
Retaining Nut 51.5 N·m (38 ft. lb.)
Fuel Tank
Bracket to Crankcase Stud 8 N·m (71 in. lb.)
Bracket to Tank Fastener 4.5 N·m (40 in. lb.)
Governor
Lever Fastener 9.5 N·m (84 in. lb.)
Gear Fastener 9.5 N·m (84 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Module Fastener 10 N·m (88 in. lb.)
Screw 10 N·m (88 in. lb.)
Mufer
Exhaust Stud 5.0 N·m (44 in. lb.)
Exhaust Stud Nut Fastener 9.5 N·m (84 in. lb.)
Retractable Starter
Fastener 8 N·m (71 in. lb.)
Rocker Arm
Stud 13.6 N·m (120 in. lb.)
Pivot Jam Nut 9.5 N·m (84 in. lb.)
Speed Control
Bracket Assembly Fastener 8 N·m (71 in. lb.)
Valve Cover
Fastener 8 N·m (71 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
7
Apply thread sealant around three full threads before assembly. No excess sealant allowed on inside or outside of
joint. Threads with preapplied sealant do not require use of additional sealant. Approved sealants include Perma-Loc
LH 150, Perma-Loc MM 115, Perma-Loc HH 120, Perma-Loc HL 126.
