FOREWORD
INTENDED USE
INTENDED USE
USE OF MACHINE
This Komatsu machine is designed to be used mainly for the following work:
Traveling with a load
DIRECTIONS OF MACHINE
In this manual, the directions of the machine (front, rear, left, right) are determined according to the view from the
operator's seat in the direction of travel (front) of the machine.
(A)
(B)
(C)
FRONT
REAR
LEFT
(D)
(E)
RIGHT
OPERATOR'S SEAT
VISIBILITY FROM OPERATOR'S SEAT
This machine complies with the visibility standard (ISO 5006).
This machine maintains a close visibility of a height of 1.5 m at a point 1 m away from the outside surface of the
machine, and a visibility for a circumference of 12 m.
