Konica Minolta DiMAGE X50 User Manual

14 GETTING UP AND RUNNING
GETTING UP AND RUNNING
CHARGING THE BATTERY
Before the camera can be used, the lithium-ion battery must be charged. Before charging
the battery, read the safety warnings on pages 3 and 4 of this manual. Only recharge the
battery with the supplied battery charger. The battery should be recharged before each
shooting session. See page 103 for battery care and storage.
1
With the battery terminals forward lower the battery into the
charger so the guides in the charger bed enter the channels
on the battery. Slide the battery forward into the charger.
Plug the power cord into the back of the charger unit (1).
Plug the other end of the cord into a live household outlet.
The included AC cord is designed for the current of the
sales region. Only use the cord in the region it was
purchased. For more on the AC cable, see page 101.
2
The indicator lamp (2) glows to show the battery is charging. The
lamp goes out when the battery has been charged. Charging
time is approximately 90 minutes. Remove the battery from the
charger. Unplug the power cord from the outlet.

Konica Minolta DiMAGE X50 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Image sensor size	1/2.5 \
Maximum image resolution	2560 x 1920 pixels
Still image resolution(s)	1600 x 1200, 2048 x 1536, 2560 x 1920
Digital zoom	4.3 x
Optical zoom	12 x
Focal length range	6.1 - 17.1 mm
Metering	Multi-segment (256 segments) / Spot
Interface	USB, Exif Print, PRINT Image Matching II
Built-in flash	Yes
Camera shutter speed	4 - 1/1000 s
Focal length (35mm film equivalent)	37 - 105 mm
Compatible memory cards	mmc, sd
Display diagonal	2 \
I/O ports	USB NTSC/PAL
Bundled software	DiMAGE Viewer
Camera playback	Slide show
Self-timer delay	10 s
Motion JPEG frame rate	15 fps
Maximum video resolution	320 x 240 pixels
Product color	Silver
Battery type	NP-700
ISO sensitivity	50, 100, 200
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	23.5 mm
Width	83.5 mm
Height	62 mm
Weight	125 g
