61
A live image is displayed in the frame. Compose
the subject inside the frame and press the
shutter-release button partway down to lock the
focus. The current recording settings are used to
capture the image and the optical zoom can be
used. Press the shutter-release button all the way
down to take the picture and complete the
operation.
Nine frame choices are shown on the LCD
monitor. Select the frame with the controller.
Press the center button to continue.
Pressing the menu button at any time during the
operation cancels the routine. The camera
memorizes any settings entered.
The frame is displayed on the background image.
Change the frame size using the up and down
keys; three sizes are available. Press the center
button to continue.
Choose the location for the pasted image by
moving the frame with the controller keys. Press
the center button to continue.
Sel.
Enter
Size
Enter
Move
Enter
Press shutter to paste.

Konica Minolta DiMAGE X50 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Image sensor size	1/2.5 \
Maximum image resolution	2560 x 1920 pixels
Still image resolution(s)	1600 x 1200, 2048 x 1536, 2560 x 1920
Digital zoom	4.3 x
Optical zoom	12 x
Focal length range	6.1 - 17.1 mm
Metering	Multi-segment (256 segments) / Spot
Interface	USB, Exif Print, PRINT Image Matching II
Built-in flash	Yes
Camera shutter speed	4 - 1/1000 s
Focal length (35mm film equivalent)	37 - 105 mm
Compatible memory cards	mmc, sd
Display diagonal	2 \
I/O ports	USB NTSC/PAL
Bundled software	DiMAGE Viewer
Camera playback	Slide show
Self-timer delay	10 s
Motion JPEG frame rate	15 fps
Maximum video resolution	320 x 240 pixels
Product color	Silver
Battery type	NP-700
ISO sensitivity	50, 100, 200
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	23.5 mm
Width	83.5 mm
Height	62 mm
Weight	125 g
