1-3-5-3 Selection of thermometer
function
Ambient temperature Ambient
temperature
Everybody Service -
Water temperature
1-3-7 Calibration - - - - -
1-3-7-1 Sensors - - - - -
1-3-7-1-1 Pressure sensor on suction side - - - - -
1-3-7-1-1-1 Value at 4 mA 0 … value at 20 mA 0 Everybody Service -
1-3-7-1-1-2 Value at 20 mA Value at 0/4 mA … 100 bar 10 bar Everybody Service -
1-3-7-1-2 Pressure sensor on discharge side - - - - -
1-3-7-1-2-1 Value at 4 mA 0 … value at 20 mA 0 Everybody Service -
1-3-7-1-2-2 Value at 20 mA Value at 0/4 mA … 100 bar 16 bar Everybody Service -
1-3-7-1-3 Pressure sensor at tank - - - - -
1-3-7-1-3-1 Value at 4 mA 0 … value at 20 mA 0 Everybody Service -
1-3-7-1-3-2 Value at 20 mA Value at 0/4 mA … 10 bar 0.306 bar Everybody Service -
1-3-7-1-4 Setpoint - - - - -
1-3-7-1-4-1 Value at 4 mA 0 … value at 20 mA 0 Everybody Service -
1-3-7-1-4-2 Value at 20 mA Value at 0/4 mA … 100 bar 16 bar Everybody Service -
1-3-7-2 Output signal - - - - -
1-3-7-2-1 Suction-side pressure - - - - -
1-3-7-2-1-1 Selection of output current
range
0 … 20 mA 4 mA … 20 mA Everybody Service -
4 mA … 20 mA
1-3-7-2-1-2 Value at 0/4 mA If selection … = 0 mA … 20 mA 0 … value at 20
mA
Everybody Service -
1-3-7-2-1-3 Value at 20 mA - Value at 0/4 mA …
100 bar
Everybody Service -
1-3-7-2-2 Discharge-side pressure - - - - -
1-3-7-2-2-1 Selection of output current
range
0 … 20 mA 4 mA … 20 mA Everybody Service -
4 mA … 20 mA
1-3-7-2-2-2 Value at 0/4 mA If selection … = 0 mA … 20 mA 0 … value at 20
mA
Everybody Service -
1-3-7-2-2-3 Value at 20 mA - - Everybody Service -
1-3-7-2-4 Tank fill level - - - - -
1-3-7-2-4-1 Selection of output current
range
0 … 20 mA 4 mA … 20 mA Everybody Service -
4 mA … 20 mA
