4 Description of the Pump (Set)
4.1 General description
Pump for handling pre-treated sewage, waste water, all types of slurries (without
stringy substances) and pulps up to 5% bone dry.
For use in the chemical and process industries, paper and pulp industries, sugar
industry, food and beverages industry, in flue gas desulphurisation, coal upgrading
plants and in industrial waste water treatment systems.
Table 6: KWP types of installation
Type of
installation
3)
Illustration Description
Figure 3 Pump set with pump directly coupled to the
motor
Figure 3Z Pump set with belt drive. Motor bracket
positioned in front of the pump.
Figure 4H Pump set with belt drive. Motor bracket
positioned on top of the pump.
4.2 Designation
Example: K W P K A 100 - 250
Table 7: Key to the designation
Code Description
KWP Type series
K Impeller type, e.g. K = channel impeller
A Additional code, e.g. A = mechanical seal
installed in conical seal chamber
100 Nominal discharge nozzle diameter [mm]
250 Nominal impeller diameter [mm]
3)
To ZN 482
4 Description of the Pump (Set)
16 of 78
KWP
