16 ELECTRICAL SYSTEM 150
Preparatory work
– Switch off all power consumers and switch off the engine.
– Remove the passenger seat. ( p. 99)
– Remove the driver's seat. ( p. 100)
S00373-10
Main work
–
Pull locking mechanism
1
in the direction of the arrow.
–
Fold open cover
2
.
S00375-10
–
Disconnect negative cable
3
of the battery.
–
Disconnect the positive cable
4
of the battery.
–
Take the battery and battery case
5
out of the battery compartment.
