23 TECHNICAL DATA 201
Suspension travel
Front 190 mm (7.48 in)
Rear 190 mm (7.48 in)
Brake system
Front Double disc brake with radially mounted four-pot brake calipers,
floating brake discs
Rear Single disc brake with dual-piston brake caliper, floating brake
disc
Brake discs - diameter
Front 320 mm (12.6 in)
Rear 267 mm (10.51 in)
Brake discs - wear limit
Front 4 mm (0.16 in)
Rear 4.5 mm (0.177 in)
Tire air pressure, solo/with passenger/full payload
Front: with cold tires 2.4 bar (35 psi)
Rear: with cold tires 2.9 bar (42 psi)
Secondary drive ratio 17:42
Chain 5/8 x 5/16” (525) X‑ring
Steering head angle 64°
Wheelbase 1,560 mm (61.42 in)
Seat height, unloaded 860/875 mm (860/875 in)
Ground clearance, unloaded 220 mm (8.66 in)
Weight without fuel, approx. 212 kg (467 lb.)
Maximum permissible front axle load 159 kg (351 lb.)
