8 ERGONOMICS 70

602818-10

–

Clean gear teeth

of the shift lever and shift shaft.

– Mount the shift lever on the shift shaft in the required position and engage the gearing.

Info

The range of adjustment is limited.

The shift lever must not come into contact with any other vehicle components

during the shift procedure.

– Mount and tighten the screw.

Guideline

Screw, shift lever M6 10 Nm

(7.4 lbf ft)

Loctite

243™
