MAINTENANCE WORK ON FRAME AND ENGINE 119
100705-10
– The position of the shift lever can be greatly varied, depending on the length of the shift
rod and the drill holes selected. As seen from the footrest, there is either a high position
of the shift lever or a low position of the shift lever .
Info
If you turn the reverse shift shaft 2 teeth on the serration of the shift shaft, you
can adjust the footrest system optimally for the upper footrest position.
– After adjusting the shift lever, check its operation. There must be a minimum distance
between the moving parts of the shift lever and other parts of the vehicle.
Guideline
Minimum clearance 5 mm (0.2 in)
