MAINTENA
NCE
WORK
ON
FRAME
AND
ENGINE
158
9.59
Changing
the
fuses
of
individual
power
consumers
Warning
Fire
hazard
The
electrical
system
can
be
overloaded
by
the
use
of
incorrect
fuses.
–
Use
only
fuses
with
the
prescribed
amperage.
Never
by-pass
or
repair
fuses.
Info
The
fuse
box
containing
the
fuses
of
individual
power
consumers
is
located
under
the
seat.
–
Switch
off
all
power
consumers
and
the
engine.
–
Remove
the
seat.
(
p.
148)
100740-10
–
Open
fuse
box
cover
.
159
161
