MAINTENANCE WORK ON FRAME AND ENGINE 140
100721-10
Warning
Danger of accidents Reduced braking efficiency due to oil or grease on the
brake discs.
– Always keep the brake discs free of oil and grease, and clean them with
brake cleaner when necessary.
– Clean screw and axle .
– Lift the front wheel into the fork, position it, and insert the wheel spindle.
– Mount and tighten screw .
Guideline
Bolt, front axle M25x1.5 45 Nm
(33.2 lbf ft)
100719-11
– Position the brake calipers and check that the brake linings are seated correctly.
– Insert bolt and tighten.
Guideline
Screw, front brake caliper M10x1.25 45 Nm
(33.2 lbf ft)
Loctite
®
243™
– Operate the hand brake lever several times until the brake pads are lying correctly on
the brake disc.
– Take the front of the motorcycle off the work stand. ( p. 96)
– Take the rear of the motorcycle off the work stand. ( p. 97)
