MAINTENANCE WORK ON FRAME AND ENGINE 190

100773-10

– Thoroughly clean the magnet  and oil screen  of the oil drain plug.

100772-11

– Mount and tighten the oil drain plugs with the magnet, O-rings and oil screen.

Guideline

Oil drain plug M20x1.5 20 Nm

(14.8 lbf ft)

–

Install the oil filter. x ( p. 193)
