TECHNICAL DATA - ENGINE TIGHTENING TORQUES 217
Screw, conrod bearing M10x1 Step 1
25 Nm (18.4 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
90°
–
Screw, timing chain tensioner release M10x1 10 Nm (7.4 lbf ft) –
Cylinder head screw M11x1.5 Tightening sequence:
Using a crisscross pattern
Step 1
15 Nm (11.1 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
90°
Step 4
90°
lubricated with engine oil
Coolant temperature sensor M12x1.5 12 Nm (8.9 lbf ft) –
Rotor screw M12x1.5 90 Nm (66.4 lbf ft) –
Spark plug M12x1.5 17 Nm (12.5 lbf ft) –
Oil drain plug M20x1.5 20 Nm (14.8 lbf ft) –
Nut, inner clutch hub M22x1.5 130 Nm (95.9 lbf ft)
Loctite
®
243™
Plug, timing-chain tensioner M24x1.5 25 Nm (18.4 lbf ft) –
Screw in generator cover M24x1.5 8 Nm (5.9 lbf ft) –
Nut, primary gear M33LHx1.5 130 Nm (95.9 lbf ft)
Loctite
®
243™
