23 TECHNICAL DATA
130
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, retaining bracket, rotary
valve
M5 6 Nm (4.4 lbf ft)
Loctite
®
2701™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, water pump wheel M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Bleeder screw, cylinder head M6 8 Nm (5.9 lbf ft)
Bleeder screw, water pump cover M6x25 8 Nm (5.9 lbf ft)
Coolant drain plug M6 10 Nm (7.4 lbf ft)
Screw, alternator cover M6 8 Nm (5.9 lbf ft)
Screw, clutch cover M6x20 10 Nm (7.4 lbf ft)
Screw, clutch cover M6x25 10 Nm (7.4 lbf ft)
Screw, clutch cover M6x30 10 Nm (7.4 lbf ft)
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft)
Screw, control lever, exhaust con-
trol
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, engine case M6 10 Nm (7.4 lbf ft)
Screw, exhaust flange M6 10 Nm (7.4 lbf ft)
Screw, gear oil level monitoring M6 8 Nm (5.9 lbf ft)
Screw, intake flange/reed valve
housing
M6 6 Nm (4.4 lbf ft)
Screw, kick starter stop plate M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, outer clutch cover M6x20 8 Nm (5.9 lbf ft)
Screw, outer clutch cover M6x50 8 Nm (5.9 lbf ft)
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, stop plate of exhaust con-
trol
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Vacuum connection, housing
breather
M6 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, cylinder head M7 18 Nm (13.3 lbf ft)
Nut, cylinder base M8 23 Nm (17 lbf ft)
Screw, cylinder base M8 10 Nm (7.4 lbf ft)
Screw, kick starter lever M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Gear oil drain plug M10x1 15 Nm (11.1 lbf ft)
Nut, rotor M12x1 50 Nm (36.9 lbf ft)
Gear oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Spark plug M14x1.25 25 Nm (18.4 lbf ft)
