6 CONTROLS 16
101667-10
(250 SX EU, 250 SX USA)
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
6.12 Kick starter
101734-10
The kick starter 1 is fitted on the right side of the engine. The top part can be
swiveled.
6.13 Foot brake lever
B00007-10
Foot brake lever 1 is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.14 Plug-in stand (All SX models)
101668-10
The holder for plug-in stand 1 is on the left side of the wheel spindle.
The plug-in stand is used to park the motorcycle.
Info
Remove the plug-in stand before riding.
6.15 Side stand (All XC models)
800211-10
The side stand 1 is on the left side of the vehicle.
