13 SERVICE WORK ON THE CHASSIS 108
H00380-11
–
Check the locking caps
for damage and tightness.
» If the locking caps are damaged or loose:
– Replace locking caps.
Link fork locking cap (61304041100)
13.15 Adjusting the chain tension
Warning
Danger of accidents Danger caused by incorrect chain tension.
– If the chain is too taut, the components of the secondary power transmission (chain, engine sprocket, rear sprocket, bearings in
the transmission and in the rear wheel) will be under additional load. In addition to premature wear, this can cause the chain
or the countershaft of the transmission to break in extreme cases. If the chain is too loose, however, it may fall off the engine
sprocket or rear sprocket and block the rear wheel or damage the engine. Ensure that the chain tension is correct and adjust it
if necessary.
Preparatory work
– Check the chain tension. ( p. 107)
– Lift the motorcycle with the rear lifting gear. ( p. 97)
