15 WHEELS, TIRES 131
203023-11
Main work
– Check the rear wheel bearing for damage and wear.
» If the rear wheel bearing is damaged or worn:
– Change the rear wheel bearing.
– Clean and grease the threads of the wheel axle and axle nut.
Long-life grease ( p. 199)
– Slide the rear wheel onto the axle.
Driving pins
engage in drilled holes
of the rim.
203021-11
–
Mount taper ring
, washer
, and nut
.
– Have an assistant operate the rear brake.
–
Tighten nut
.
Guideline
Nut, rear axle M50x1.5 250 Nm
(184.4 lbf ft)
Lock the locking
wire with locking
varnish
