21 TECHNICAL DATA 166

21.8 Shock absorber

Shock absorber part number 90604010000

Shock absorber WP Suspension

Spring preload

Standard 3 clicks

Full payload 6 clicks

Static sag 15 mm (0.59 in)

Riding sag 45… 50 mm (1.77… 1.97 in)

Fitted length 300 mm (11.81 in)

21.9 Chassis tightening torques

Exhaust clamp - 19 Nm (14 lbf ft) –

Helmet holder screw EJOT PT

3 Nm (2.2 lbf ft) –

Screw, chain guard EJOT PT

4 Nm (3 lbf ft) –

Screw, headlight EJOT PT

4 Nm (3 lbf ft) –

Remaining screws, chassis M4 4 Nm (3 lbf ft) –

Screw, EFI control unit M4 5 Nm (3.7 lbf ft) –

Screw, license plate lamp M4 2 Nm (1.5 lbf ft) –

Screw, trim, subframe, bottom M4 5 Nm (3.7 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, brake line holder, rear M5 7 Nm (5.2 lbf ft) Loctite

243™

Screw, chain guard M5 4 Nm (3 lbf ft) Loctite

243™

Screw, fuel pump M5 5 Nm (3.7 lbf ft) –
