21 TECHNICAL DATA 170
Screw, front footrest bracket M10x1.25 46 Nm (33.9 lbf ft) –
Screw, side stand bracket M10x1.25 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10x1.25 50 Nm (36.9 lbf ft) –
Stud, rear sprocket M10x1.25 50 Nm (36.9 lbf ft) –
Nut, rear wheel spindle M14x1.5 60 Nm (44.3 lbf ft) –
Nut, swingarm pivot M14x1.5 140 Nm (103.3 lbf ft) –
Screw, top steering head M16x1.5 52 Nm (38.4 lbf ft) –
Swingarm bearing adjusting ring M22x1 Tighten and ensure that there
is no play
–
Nut, steering head M30x1 Step 1
50 Nm (36.9 lbf ft)
2nd stage (loosen, counter-
clockwise)
2 turns
Step 3
5 Nm (3.7 lbf ft)
–
