ELECTRICAL SYSTEM 124

101146-11

– Position holes  onto holding lugs .

101145-10

– Position the headlight mask. Mount and tighten screws .

Guideline

Remaining chassis screws M6 10 Nm (7.4 lbf ft)

– Check that the lighting is functioning properly.

13.7Changing the parking light bulb

Note

Damage to reflector Reduced luminance.

– Grease on the lamp will evaporate due to the heat and be deposited on the reflector. Clean the lamp and keep it free of grease before

mounting.

– Switch off all power consumers and the engine.
