SERVICE WORK ON THE CHASSIS 84

101165-10

– Remove screw .

– Carefully push the fuel tank back.

10.10Positioning the fuel tank

– Carefully push the fuel tank forward.

101165-11

– Mount and tighten screw  with the collar bushing.

Guideline

Remaining chassis screws M6 10 Nm (7.4 lbf ft)
