TUNING THE ENGINE 152
15.2Adjusting the play in the throttle cable x
700608-01
– Move the handlebar to the straight-ahead position.
– Use the KTM diagnostics tool to set the throttle stepper motor to the basic position.
– Loosen counter nut .
– Set the play in the throttle cable by turning adjusting screw .
Guideline
Play in throttle cable 3… 5 mm (0.12… 0.2 in)
– Tighten counter nut .
15.3Ignition curve plug-in connector
101170-01
The plug-in connection is located under the seat in front of the fuse box.
By disconnecting the plug-in connector, the ignition curve for fuel with an octane rating
below 95 (ROZ 95/RON 95/PON 91) is activated. While the engine will have a slightly
lower power output, this setting prevents engine damage by hindering spark knocking due
to poor fuel quality.
Possible states
• Plug-in connector disconnected – Fuel with an octane rating of 80 to 94 (RON) can be
used for one tank full.
• Plug-in connector connected – Fuel with an octane rating of 95 or higher can be used.
