CONTROLS 48

5.33Tool set

101105-10

The tool set  is located in the storage compartment under the seat.

5.34Helmet lock

101106-10

Warning

Danger of accidents Impairment of ride behavior and vehicle operation if a helmet

or helmet lock is attached to the vehicle.

– Do not use the helmet lock for holding a helmet or other objects during the jour-

ney. Always remove the helmet lock before starting out.

The steel cable  in the tool set can be used to lock a helmet to the vehicle to prevent it

from being stolen.
