TUNING THE ENGINE 154

15.6Adjusting the basic position of the shift lever x

101172-10

– Remove screw  and remove shift lever .

101173-10

– Clean gear teeth  of the shift lever and shift shaft.

– Mount the shift lever on the shift shaft in the required position and engage the gearing.

Info

The range of adjustment is limited.

The shift lever must not come into contact with any other vehicle components

during the shift procedure.

– Mount and tighten screw.

Guideline

Screw, shift lever M6 10 Nm

(7.4 lbf ft)

Loctite

243™
