CONTROLS 13
5.6Electric starter button (EXC‑F EU, EXC‑F SIX DAYS, XCF‑W)
400198-10
The electric starter button is fitted on the right side of the handlebar.
Possible states
• Electric starter button in basic position
• Electric starter button pressed – In this position, the electric starter is actuated.
5.7Electric starter button (EXC‑F AUS)
500131-11
The electric starter button is fitted on the right side of the handlebar.
Possible states
• Electric starter button in basic position
• Electric starter button pressed – In this position, the electric starter is actuated.
5.8Light switch (EXC-F, EXC‑F SIX DAYS)
500134-12
The light switch is fitted on the left side of the handlebar.
Possible states
Light off – Light switch is turned to the right. In this position, the light
is switched off.
Low beam on – Light switch is in the central position. In this position,
the low beam and tail light are switched on.
High beam on – Light switch is turned to the left. In this position, the
high beam and the tail light are switched on.
5.9Horn button (EXC-F, EXC‑F SIX DAYS)
500134-11
The horn button is fitted on the left side of the handlebar.
Possible states
• Horn button in neutral position
• Horn button pressed – The horn is operated in this position.
5.10Turn signal switch (EXC-F, EXC‑F SIX DAYS)
500145-10
Turn signal switch is fitted on the left side of the handlebar.
Possible states
Turn signal light off – Turn signal switch is in the central position.
Turn signal light, left, on – Turn signal switch turned to the left.
Turn signal light, right, on – Turn signal switch turned to the right.
