CONTROLS 23
7.4Closing filler cap
400199-11
– Replace the filler cap and turn clockwise until the release button locks in place.
Info
Route the fuel tank breather hose without kinking.
7.5Choke (EXC-F EU, EXC‑F SIX DAYS)
500136-10
The choke lever is fitted on the left side of the handlebar.
Activating the choke function frees an opening through which the engine can draw
extra fuel. This gives a richer fuel-air mixture, which is needed for a cold start.
Info
If the engine is warm, the choke function must be deactivated.
Possible states
• Choke function activated – The choke lever is pulled to the stop.
• Choke function deactivated – The choke lever is pushed back to the stop.
7.6Choke (XCF‑W, SX‑F, EXC‑F AUS)
600660-10
Choke is fitted on the left side of the carburetor.
Activating the choke function frees an opening through which the engine can draw
extra fuel. This gives a richer fuel-air mixture, which is needed for a cold start.
Info
If the engine is warm, the choke function must be deactivated.
Possible states
• Choke function activated – The choke lever is pulled out to the stop.
• Choke function deactivated – The choke lever is pushed in to the stop.
7.7Shift lever
600661-13
Shift lever is mounted on the left side of the engine.
600661-10
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
