6
CONTROL
S
23
6.21
Unlocking
the
steering
400731-01
–
Insert
the
key
in
the
steering
lock
(
p.
22),
turn
it
to
the
left,
pull
it
out,
and
turn
it
to
the
right.
Remove
the
key.
You
can
now
steer
the
bike
again.
Info
Never
leave
the
key
in
the
steering
lock.
24
26
