12 SERVICE WORK ON THE CHASSIS
80
A00061-10
Main work
– Wash the air filter thoroughly in special cleaning liquid and
allow it to dry properly.
Air filter cleaner ( p. 162)
Info
Only press the air filter to dry it, never wring it out.
– Oil the dry air filter with a high quality filter oil.
Oil for foam air filter ( p. 162)
– Clean the air filter box.
– Check the intake flange for damage and firm seating.
Finishing work
– Install the air filter. ( p. 79)
– Install the air filter box cover. ( p. 78)
12.28 Sealing the air filter box
Preparatory work
– Remove the air filter box cover. ( p. 77)
S00847-10
Main work
–
Seal the air filter box in the marked area
A
.
Finishing work
– Install the air filter box cover. ( p. 78)
12.29 Securing the air filter box cover
Preparatory work
– Remove the air filter box cover. ( p. 77)
S00846-10
Main work
–
Drill a hole at marking
A
.
Guideline
Diameter 6 mm (0.24 in)
Finishing work
– Install the air filter box cover. ( p. 78)
