TROUBLESHOOTING 20
129
Faults Possible cause Action
Engine has too little power Fuel feed interrupted – Check the fuel tank breather.
– Clean the fuel tap.
– Check/set the carburetor components.
Air filter very dirty – Clean the air filter and air filter box.
( p. 67)
Exhaust system leaky,
deformed or too little glass
fiber yarn filling in main
silencer
– Check exhaust system for damage.
– Change glass fiber yarn filling in the
main silencer. ( p. 69)
Fault in ignition system – Check the ignition system.
Diaphragm or reed valve hous-
ing damaged
– Check the diaphragm and reed valve
housing.
Engine stalls or is popping into
the carburetor
Lack of fuel
(All SX models)
– Turn tap handle of the fuel tap to
the ON position.
(All XC models)
– Turn tap handle of the fuel tap to
the ON position.
(All XC models)
– Turn tap handle of the fuel tap to
the RES position.
– Refuel. ( p. 34)
Engine takes in bad air – Check the intake flange and carburetor
for tightness.
The connector or ignition coil is
loose or oxidized
– Clean the connector and treat it with
contact spray.
Engine overheats Too little coolant in cooling sys-
tem
– Check the cooling system for leakage.
– Check the coolant level. ( p. 106)
Too little air stream – Switch off engine when stationary.
Radiator fins very dirty – Clean the radiator fins.
Foam formation in cooling sys-
tem
– Drain the coolant. ( p. 107)
– Refill with coolant. ( p. 108)
Damaged cylinder head or
cylinder head gasket
– Check the cylinder head and cylinder
head gasket.
Bent radiator hose – Change the radiator hose.
White smoke emission (steam
in exhaust gas)
Damaged cylinder head or
cylinder head gasket
– Check the cylinder head and cylinder
head gasket.
Gear oil exits at the vent hose Too much gear oil added – Check the gear oil level. ( p. 121)
Water in the gear oil Damaged shaft seal ring or
water pump
– Check the shaft seal ring and water
pump.
